e3 MAX AL21
Long haul steer tire with long mileage and fuel efficiency
Smart Way
Extended Warranty
Application
-
Long Haul
Tractor/Trailer
Recommended
/tt/steer(all)-tractor-trailer-1.svg){kind=icon}
/tt/steer(all)-tractor-trailer-2.svg){kind=icon}
Long haul steer tire with long mileage and fuel efficiency
.jpg)
High mileage, fuel efficiency
and good traction with optimized sipe
Lateral & semi-groove sipe
Optimized lateral sipe and semi-groove sipe provides better traction and enhances even wear for superior performance.
-
.jpg)
Lateral sipe
-
.jpg)
Semi-groove sipe
Round-edge sipe
Rounded shape at the edge of the sipe prevents tearing and cracking.
.jpg)
.jpg)
High mileage, fuel efficiency and good traction with optimized sipe
-
Innovative side decoupling groove
Prevents uneven wear by reducing movement between sidewall and shoulder.
.jpg)
Prevents uneven wear by reducing movement between sidewall and shoulder.
.jpg)
Best performance with even wear
Improved grip force
Expanded belt provides equal road grip which results in even wear and better performance.
-
.jpg)
Old
-
.jpg)
AL21
AL21 has a stabilized footprint which provides longer mileage by decreasing uneven wear.
.jpg)
Test Result
.jpg)
Mileage
Mileage improved 23% compared to its predecessor.
.jpg)
Rolling Resistance
Improved Rolling Resistance compared to its competitors.
-
Spec
- 22.5”
- 24.5”
-
11R22.5
- Material Code 3003108
- TT/TL L
- Ply Rating 14
- Measuring Rim 8.25X22.5
- Section Width(inch) 11.1
- Tread Width(inch) 8.1
- Tread Depth(32nds) 19
- Static Loaded Radius(inch) 19.3
- Overall Diameter(inch) 41.4
- Tire Weight(lbs.) 121
- M+S N
- 3PMSF N
- Max Speed (mph) 75
- Origin Korea
- OEM DTNA
-
11R22.5
- Material Code 3003109
- TT/TL L
- Ply Rating 16
- Measuring Rim 8.25X22.5
- Section Width(inch) 11.1
- Tread Width(inch) 8.1
- Tread Depth(32nds) 19
- Static Loaded Radius(inch) 19.4
- Overall Diameter(inch) 41.4
- Tire Weight(lbs.) 121
- M+S N
- 3PMSF N
- Max Speed (mph) 75
- Origin Korea
- OEM DTNA
-
285/75R24.5
- Material Code 3003112
- TT/TL L
- Ply Rating 14
- Measuring Rim 8.25×24.5
- Section Width(inch) 10.9
- Tread Width(inch) 8.1
- Tread Depth(32nds) 19
- Static Loaded Radius(inch) 19.4
- Overall Diameter(inch) 41.5
- Tire Weight(lbs.) 119
- M+S N
- 3PMSF N
- Max Speed (mph) 75
- Origin Korea
-
295/75R22.5
- Material Code 3002431
- TT/TL L
- Ply Rating 14
- Measuring Rim 8.25X22.5
- Section Width(inch) 11.4
- Tread Width(inch) 8.5
- Tread Depth(32nds) 19
- Static Loaded Radius(inch) 18.7
- Overall Diameter(inch) 40.2
- Tire Weight(lbs.) 116
- M+S N
- 3PMSF N
- Max Speed (mph) 75
- Origin Korea
- OEM DTNA
-
295/75R22.5
- Material Code 3002488
- TT/TL L
- Ply Rating 16
- Measuring Rim 8.25X22.5
- Section Width(inch) 11.4
- Tread Width(inch) 8.5
- Tread Depth(32nds) 19
- Static Loaded Radius(inch) 18.7
- Overall Diameter(inch) 40.2
- Tire Weight(lbs.) 116
- M+S N
- 3PMSF N
- Max Speed (mph) 75
- Origin Korea
- OEM DTNA
