Smart Flex DH35

New all season tires designed for variable road conditions

M+S 3PMSF

Application
  • Regional Haul
Truck Recommended
1Recently viewed products
    • Dynapro HP2

      SUV用高性能タイヤ:The new Dynapro HP2

    Rib type tread pattern design and multi 3-Dimensional Sipes ensure low rolling resistance and excellent driving performance.

    Hankook Tire & Technology-Tires-Smart-Smart Flex-DH35-Rib type tread pattern design and multi 3-Dimensional Sipes ensure low rolling resistance and excellent driving performance

    Pattern design

    Wide tread with 4 zigzag grooves

    Wide tread with 4 zigzag grooves enables high mileage and excellent driving performance in variable conditions.

    • Conventional
    • Smartflex DH35

    Multi 3-Dimensional Sipes

    The special tread pattern design with multi 3-Dimensional Sipes offers low rolling resistance and outstanding traction.

    Innovative rib type tread pattern design

    Special tread pattern design for low rolling resistance and excellent traction performance across multi applications.

    • Semi groove rib
    • Block rib

    Pattern design

    • TBR Technology

      Stiffness Control Contour Theory Technology(SCCT Technology)

      SCCT Technology is designed to reduce profile deformation. If the carcass profile is not kept constant, the internal force on the carcass will be concentrated on a specific point, belt edge or carcass turn up edge. In contrast, SCCT Technology controls the dispersion of internal force for better durability.

      Stiffness Control Contour Theory Technology(SCCT Technology)

      SCCT Technology is designed to reduce profile deformation. If the carcass profile is not kept constant, the internal force on the carcass will be concentrated on a specific point, belt edge or carcass turn up edge. In contrast, SCCT Technology controls the dispersion of internal force for better durability.

    Test Result

    Improved performance compared to predecessor tire

    Mileage field test result

    e3maxal21_video_thumbnail
    • Spec

      • 19.5”
      • 225/70R19.5
        • Material Code 3003611
        • TT/TL L
        • Ply Rating 14
        • Measuring Rim 6.75X19.5
        • Section Width(inch) 8.8
        • Tread Width(inch) 7.2
        • Tread Depth(32nds) 17
        • Static Loaded Radius(inch) 15.1
        • Overall Diameter(inch) 32.2
        • Tire Weight(lbs.) 64
        • M+S Y
        • 3PMSF Y
        • Max Speed (mph) 87
        • Origin Korea
      • 245/70R19.5
        • Material Code 3003716
        • TT/TL L
        • Ply Rating 16
        • Measuring Rim 7.5x19.5
        • Section Width(inch) 9.9
        • Tread Width(inch) 8.8
        • Tread Depth(32nds) 17
        • Static Loaded Radius(inch) 15.5
        • Overall Diameter(inch) 33.2
        • Tire Weight(lbs.) 77
        • M+S Y
        • 3PMSF Y
        • Max Speed (mph) 81
        • Origin Korea
      • 265/70R19.5
        • Material Code 3002700
        • TT/TL L
        • Ply Rating 14
        • Measuring Rim 7.5x19.5
        • Section Width(inch) 10.2
        • Tread Width(inch) 9.3
        • Tread Depth(32nds) 16
        • Static Loaded Radius(inch) 15.8
        • Overall Diameter(inch) 34.3
        • Tire Weight(lbs.) 86
        • M+S Y
        • 3PMSF Y
        • Max Speed (mph) 81
        • Origin Korea
        • OEM MAN/SCANIA
